Paradise Engineering Ltd. has designed advance 3-Phase Electronic metering solutions with respect to the market demand. Three-phase static energy meter is based on special large scale integrated circuit and SMT technology; by adopting microelectronics and computer technology as core technology and depending on modern management. We developed this metering product with high dependability and precision. It’s one of the newest energy metering products in the world. It meets all technical requirements of IEC 62053-21: class 1 and class 2 static alternating active watt-hour meter, it measures positive and negative active power energy with frequency of 50/60Hz in three-phase electricity network.
Technical Specifications:
Accuracy class: 1.0 class, 2.0 class
Meter Constant (imp/kwh):1000, 1100
Voltage: 400 Volt
Rated Frequency: 50/60 Hz
Accord standard: IEC62053; IEC61036; GB/T17215-2002
Life: 10 years
Rated Current: 10 (100)
Normal working temperature: -30 ~+55
Limit working temperature: -40 ~+70
Relative humidity: annual average 95%
Voltage circuit power consumption 1.0W(6VA)
Current circuit power consumption 1.0VA
